Technical Details
Color
Main color: White
Secondary color: Transparent
Dimensions / Measurements
Length / Depth: 478 mm
Width: 290 mm
Height: 471 mm
Weight: 16 kg
Case
Case type: Mid-tower
Motherboard Support
Compatible motherboard form factors: ATX, E-ATX, Micro-ATX, Mini-ITX
Maximum motherboard form factor: E-ATX
Internal Dimensions
Maximum CPU cooler height: 167 mm
Maximum graphics card length: 455.7 mm
Maximum power supply length / depth: 220 mm
Display
Display included: No
Power Supply
Power supply included: No
Power supply form factor: ATX
Power supply position: Rear side / bottom
Cable Specifications
Riser cable included: No
Fan Support
Fan mounts (bottom): 120 mm fans (3×), 140 mm fans (3×)
Fan mounts (rear): 120 mm fan (1×)
Fan mounts (side): 120 mm fans (3×), 140 mm fans (3×)
Fan mounts (top): 120 mm fans (3×), 140 mm fans (3×)
Maximum number of fans: 10
120 mm fans: 10
140 mm fans: 9
Radiator Support
Maximum radiator compatibility:
2× dual (280 mm), 3× dual (240 mm), 3× triple (360 mm)
Radiator / AIO support (bottom): 240 mm, 280 mm, 360 mm
Radiator / AIO support (side): 240 mm, 280 mm, 360 mm
Radiator / AIO support (top): 240 mm, 360 mm, 420 mm
Drive Bays
Maximum 2.5" drives: 8
Maximum 3.5" drives: 4
Maximum 5.25" drives: 0
2.5" internal: 6
3.5" internal: 2
1× 3.5" / 1× 2.5" internal (combined): 2
Hot-swap drive bays: No
External Connections
Front I/O – USB Type-C ports (total): 1
Front I/O – USB Type-A ports (total): 2
USB 3.1 (external) Type-C: 1
USB 3.0 (external) Type-A: 2
Audio outputs & inputs:
1× combined output/input (3.5 mm jack, 4-pole, TRRS)
Case Features
I/O position: Front
Side panel: With window
Vertical GPU mount: No
Adjustable vertical GPU mount: No
Front door: No
Cable management: No
Dust filters included: Yes
Filter position: Bottom
Sound dampening: No
Motherboard tray: No
Remote control included: No
Carrying handle: No
Back Connect
Back Connect: No
Expansion Slots
Expansion / PCI slots: 7
Features
Case pass-through: No
Connectivity Options
Card reader: No
Fan Header
Fan control / fan hub: No
Mounting
Case VESA-mountable: No
Internal monitor mount: No
Material
Materials: Aluminum, steel, tempered glass
Lighting
Lighting / RGB: Yes
RGB control: Yes
Lighting color: RGB
Product Series
Product series / family: O11
Package Contents
Pre-installed fans: No
Fans pre-installed: None
